MECO DC MR 65 EDM Moving Coil Meter (HSN 9030)

The MECO DC MR 65 EDM Moving Coil Meter (HSN 9030) is a precision analog measuring instrument designed for accurate DC current and DC voltage measurement in electrical control panels, laboratories, industrial equipment, educational institutions, and power distribution systems. Manufactured by MECO Instruments, this moving coil meter offers dependable accuracy, long-term stability, and reliable performance for professional electrical applications.

Technical Details-

• Model No.:, MR65, MR100, MR120

• Current (µA) : 100µA to 750µA

• Current (mA) : 1mA to 750mA

• Current (A ) : 1A to 50A, 0-5A to 0-5000 A/75mV (for MR60 model direct 10A DC only - Above 10A use with external shunt)

• Voltage (mV) : 50mV to 750mV

• Voltage (V) : 1V to 1000V

• AC Range

• Current (A) : 1A or 5A (From 100mA to 5A AC, use with eternal CT box, supplied with the instrument)

• Voltage (V) : 10V to 1000V

• Volmeter, Ammeter, Galvanometer

• Accuracy: Class +2 F.S.D. Case : Clear transparent front cover.

• Scale length: 85 mm (Approx) with knife edge

• Pointer and anti parallex mirror scale.

• Desk Stand : Front terminal unbreakable ABS black.

• Packing : Thermocol Box.

• Exact measurement

• Rigid design

• Defect free

Choose the MECO DC MR 65 EDM Moving Coil Meter for accurate DC measurement, reliable operation, low maintenance, and trusted MECO quality.
